Volume 52,Issue 6,2023 Table of Contents
2023, 52(6):1977-1984.
DOI: 10.12442/j.issn.1002-185X.20220960
Abstract:
The fourth generation single crystal superalloy DD15 with Re content of 5wt%, 6wt%, and 7wt% was cast in the directionally solidified furnace, while other alloying elements were basically the same in content. The long term aging after full heat treatment was performed at 1100 °C for 1000 h. The stress rupture tests of the alloy were conducted under 1100 °C/137 MPa. The effect of Re content on the microstructure and stress rupture properties of the alloy was investigated. The results show that the size of γ′ phase decreases, the volume fraction and cubic degree of γ′ phase slightly increase with increase in Re content. After long term aging, the γ′ phase coarsens, and the drafting rate, precipitate rate and volume fraction of TCP phase are all improved with increase in Re content. With the increase in Re content, the microstructure stability and the stress rupture life of the alloy decline significantly. The three ruptured specimens all exhibit the presence of TCP phase. The amount of TCP phases increases greatly with increase in Re content. TCP phase can be the site of crack initiation. This is the main reason for the decrease in stress rupture life of the alloy with increase in Re content. The dislocation networks formed at the γ/γ′ interface of ruptured specimen turn denser with increase in Re content. Re has a strong segregation tendency in γ matrix. The partition ratio of Re rises significantly with increase in Re content. The lattice misfit of the alloy becomes larger toward negative with increase in Re content.
The fourth generation single crystal superalloy DD15 with Re content of 5wt%, 6wt%, and 7wt% was cast in the directionally solidified furnace, while other alloying elements were basically the same in content. The long term aging after full heat treatment was performed at 1100 °C for 1000 h. The stress rupture tests of the alloy were conducted under 1100 °C/137 MPa. The effect of Re content on the microstructure and stress rupture properties of the alloy was investigated. The results show that the size of γ′ phase decreases, the volume fraction and cubic degree of γ′ phase slightly increase with increase in Re content. After long term aging, the γ′ phase coarsens, and the drafting rate, precipitate rate and volume fraction of TCP phase are all improved with increase in Re content. With the increase in Re content, the microstructure stability and the stress rupture life of the alloy decline significantly. The three ruptured specimens all exhibit the presence of TCP phase. The amount of TCP phases increases greatly with increase in Re content. TCP phase can be the site of crack initiation. This is the main reason for the decrease in stress rupture life of the alloy with increase in Re content. The dislocation networks formed at the γ/γ′ interface of ruptured specimen turn denser with increase in Re content. Re has a strong segregation tendency in γ matrix. The partition ratio of Re rises significantly with increase in Re content. The lattice misfit of the alloy becomes larger toward negative with increase in Re content.
2023, 52(6):1985-1993.
DOI: 10.12442/j.issn.1002-185X.20221001
Abstract:
The low-cycle fatigue performance and fracture damage mechanism of Ni-based single crystal superalloy were investigated at 530 °C. Results show that at 530 °C, the fatigue crack of the single crystal superalloy generally appears on the surface, sub-surface or inside of the sample. When there are casting defects on the sub-surface, fatigue crack will arise preferentially from the defects. Under the condition of large strain amplitude (>0.85%), the alloy shows obvious cyclic hardening behavior during the fatigue cycle, and the cyclic stress response curve tends to be stable when the strain amplitude is lower than 0.85%. The plastic deformation of Ni-based single crystal superalloy is mainly proceeded by slip. At 530 °C, the fracture of single crystal superalloy is mainly caused by octahedral slip mechanism, and the main slip system is {111} <110>. According to the sectional structure characteristics of the fracture, no obvious plastic deformation occurs near the source area. The characteristic of fatigue striation can be seen in the stable extension of the crack, and a lot of cross slip bands exist at the slip step in the rapid crack extension stage. By electron backscattered diffraction analysis, there are obvious plastic deformation on the fracture surface at the junction of different slip planes, and the γ matrix and cubic γ' phase near the fracture surface are seriously distorted. No obvious oxidation is observed on the surface of fatigue fracture at 530 °C .
The low-cycle fatigue performance and fracture damage mechanism of Ni-based single crystal superalloy were investigated at 530 °C. Results show that at 530 °C, the fatigue crack of the single crystal superalloy generally appears on the surface, sub-surface or inside of the sample. When there are casting defects on the sub-surface, fatigue crack will arise preferentially from the defects. Under the condition of large strain amplitude (>0.85%), the alloy shows obvious cyclic hardening behavior during the fatigue cycle, and the cyclic stress response curve tends to be stable when the strain amplitude is lower than 0.85%. The plastic deformation of Ni-based single crystal superalloy is mainly proceeded by slip. At 530 °C, the fracture of single crystal superalloy is mainly caused by octahedral slip mechanism, and the main slip system is {111} <110>. According to the sectional structure characteristics of the fracture, no obvious plastic deformation occurs near the source area. The characteristic of fatigue striation can be seen in the stable extension of the crack, and a lot of cross slip bands exist at the slip step in the rapid crack extension stage. By electron backscattered diffraction analysis, there are obvious plastic deformation on the fracture surface at the junction of different slip planes, and the γ matrix and cubic γ' phase near the fracture surface are seriously distorted. No obvious oxidation is observed on the surface of fatigue fracture at 530 °C .
2023, 52(6):2118-2125.
DOI: 10.12442/j.issn.1002-185X.20220406
Abstract:
The excellent mechanical properties of nickel base single crystal superalloy are mainly due to its ordered L12 structure γ? (Ni3Al). In order to study the effect of laser shock γ?, the molecular dynamics model of single crystal Ni3Al was constructed by molecular dynamics method, and the microstructure evolution behaviors of [100], [110] and [111] were analyzed. The results show that the plastic deformation mechanism of [100] crystal shock is the transformation from FCC phase to BCC phase, and the content of BCC phase increases with the increase of shock pressure; The plastic deformation mechanism of [110] and [111] crystal direction shock is dislocation slip, and the [110] crystal direction slip system is mainly (1)[011] and (11)[01], The [111] crystal slip system is mainly (1)[10] and (11)[101],the dislocations produced are mainly 1/6<112>(Shockley). However, with the increase of impact pressure, the plastic deformation mechanism is the transformation from FCC phase to BCC phase, and disordered structure is produced at the same time.
The excellent mechanical properties of nickel base single crystal superalloy are mainly due to its ordered L12 structure γ? (Ni3Al). In order to study the effect of laser shock γ?, the molecular dynamics model of single crystal Ni3Al was constructed by molecular dynamics method, and the microstructure evolution behaviors of [100], [110] and [111] were analyzed. The results show that the plastic deformation mechanism of [100] crystal shock is the transformation from FCC phase to BCC phase, and the content of BCC phase increases with the increase of shock pressure; The plastic deformation mechanism of [110] and [111] crystal direction shock is dislocation slip, and the [110] crystal direction slip system is mainly (1)[011] and (11)[01], The [111] crystal slip system is mainly (1)[10] and (11)[101],the dislocations produced are mainly 1/6<112>(Shockley). However, with the increase of impact pressure, the plastic deformation mechanism is the transformation from FCC phase to BCC phase, and disordered structure is produced at the same time.
2023, 52(6):2134-2140.
DOI: 10.12442/j.issn.1002-185X.20220431
Abstract:
In this paper,we used ?1.2mm ER-GH4169 welding wire to prepare columnar array structure on 5mm thick Q235 carbon steel substrate by CMT-Pin additive technique,and investigated the Pin forming process and tissue characteristics.The results show that when the Ball/Cyl Adaptation parameter is negative,the Pin head shape is Cylindrical;when the Ball/Cyl Adaptation is non-negative,the Pin head shape is Ball;Altitude Adaptation controls the height of Pin growth,and the Pin height is obtained between (2.30~4.96)mm.The microstructure of Pins is divided into Pin axis zone,fusion zone,and base material zone;Pin axis area has a large number of columnar crystals,which grow outward along the axis; in the fusion area,the columnar crystals change from fine crystals to coarse crystals along the Pin axis upward,and the fusion area is a very fine fusion line,with a large number of strips of Laves phase precipitated between the crystals;in the base material area,there is a tissue of light and dark interlayer.
In this paper,we used ?1.2mm ER-GH4169 welding wire to prepare columnar array structure on 5mm thick Q235 carbon steel substrate by CMT-Pin additive technique,and investigated the Pin forming process and tissue characteristics.The results show that when the Ball/Cyl Adaptation parameter is negative,the Pin head shape is Cylindrical;when the Ball/Cyl Adaptation is non-negative,the Pin head shape is Ball;Altitude Adaptation controls the height of Pin growth,and the Pin height is obtained between (2.30~4.96)mm.The microstructure of Pins is divided into Pin axis zone,fusion zone,and base material zone;Pin axis area has a large number of columnar crystals,which grow outward along the axis; in the fusion area,the columnar crystals change from fine crystals to coarse crystals along the Pin axis upward,and the fusion area is a very fine fusion line,with a large number of strips of Laves phase precipitated between the crystals;in the base material area,there is a tissue of light and dark interlayer.
2023, 52(6):2243-2252.
DOI: 10.12442/j.issn.1002-185X.20220589
Abstract:
The effects of heat treatment on the microstructures and rupture properties at 1070 ℃/140 MPa of a hot-corrosion resistant single crystal superalloy was investigated. The results show that long-term homogenization heat treatment significantly reduces element segregation. With the extension of homogenization time, the area fraction of micropores gradually increases, the average size keeps increasing, and the density of micropores increases firstly and then decreases. With the increase of primary aging temperature, the size of γ" phase enlarge gradually, the area fraction of γ" phase frist increases and then decreases. The stress rupture life of the alloy increases first and then decreases with the increase of the primary aging temperature. When the primary aging temperature is 1100 ℃, the size of the cubic γ" phase is about 370 nm and the squareness is better, the area fraction of the γ" phase is the largest and the stress rupture life is the highest. The stress rupture fracture is characterized by ductile fracture. The carbides and micropores at the sub-grain boundary are the main crack sources that cause the stress rupture fracture of the sample.
The effects of heat treatment on the microstructures and rupture properties at 1070 ℃/140 MPa of a hot-corrosion resistant single crystal superalloy was investigated. The results show that long-term homogenization heat treatment significantly reduces element segregation. With the extension of homogenization time, the area fraction of micropores gradually increases, the average size keeps increasing, and the density of micropores increases firstly and then decreases. With the increase of primary aging temperature, the size of γ" phase enlarge gradually, the area fraction of γ" phase frist increases and then decreases. The stress rupture life of the alloy increases first and then decreases with the increase of the primary aging temperature. When the primary aging temperature is 1100 ℃, the size of the cubic γ" phase is about 370 nm and the squareness is better, the area fraction of the γ" phase is the largest and the stress rupture life is the highest. The stress rupture fracture is characterized by ductile fracture. The carbides and micropores at the sub-grain boundary are the main crack sources that cause the stress rupture fracture of the sample.
2023, 52(6):2302-2308.
DOI: 10.12442/j.issn.1002-185X.20220651
Abstract:
Laser powder-bed fusion (L-PBF) technology processes unique advantages in building complex-shape alloys. This paper invesgated the microstructure and high temperature low-cycle fatigue behavior of L-PBFed GH3536 superalloy in 855℃, and revealed the influence of heat treatment on microstructure and fatigue performance. By combining with different fatigue life prediction models, the fatigue damage behavior of L-PBFed GH3536 superalloy in various strain amplitudes was further discussed. These results are important for high temperature low-cycle fatigue life prediction and application of additive manufactured samples.
Laser powder-bed fusion (L-PBF) technology processes unique advantages in building complex-shape alloys. This paper invesgated the microstructure and high temperature low-cycle fatigue behavior of L-PBFed GH3536 superalloy in 855℃, and revealed the influence of heat treatment on microstructure and fatigue performance. By combining with different fatigue life prediction models, the fatigue damage behavior of L-PBFed GH3536 superalloy in various strain amplitudes was further discussed. These results are important for high temperature low-cycle fatigue life prediction and application of additive manufactured samples.
2023, 52(6):2309-2316.
DOI: 10.12442/j.issn.1002-185X.20220465
Abstract:
In present work the stress rupture property and related microstructure evolution of FB2 rotor steel are investigated by metallographic analysis, scanning electron microscope and transmission electron microscope. The investigation shows that the microstructure of FB2 rotor steel is composed of tempered martensite. Large amount of fine M23C6 carbides precipitates on original austenite grain boundary and in matrix. Decomposition and broaden of martensite lath can be found with prolonging stress rupture duration. The dislocation density decreases at the same time. Meanwhile, the M23C6 carbides located at grain boundary and martensite lath boundary grows. Laves phase gradually grows at original austenite grain boundary and aggregates into a chain distribution. The microstructure evolution at high temperature can apparently influence high temperature stress rupture property. While the FB2 roto steel can still meet the requirement that the stress is higher than 100 MPa after 630℃stress rupture test for 105h.
In present work the stress rupture property and related microstructure evolution of FB2 rotor steel are investigated by metallographic analysis, scanning electron microscope and transmission electron microscope. The investigation shows that the microstructure of FB2 rotor steel is composed of tempered martensite. Large amount of fine M23C6 carbides precipitates on original austenite grain boundary and in matrix. Decomposition and broaden of martensite lath can be found with prolonging stress rupture duration. The dislocation density decreases at the same time. Meanwhile, the M23C6 carbides located at grain boundary and martensite lath boundary grows. Laves phase gradually grows at original austenite grain boundary and aggregates into a chain distribution. The microstructure evolution at high temperature can apparently influence high temperature stress rupture property. While the FB2 roto steel can still meet the requirement that the stress is higher than 100 MPa after 630℃stress rupture test for 105h.
2023, 52(6):1994-2001.
DOI: 10.12442/j.issn.1002-185X.20220826
Abstract:
The Maxwell 3D module in Ansys Electromagnetics Suite was used to establish a mathematical and physical model for electromagnetic field in the vacuum arc remelting process of titanium alloy, and the interaction law of current, magnetic field and electromagnetic force in the melting process was analyzed. The results show that the current in the ingot is centripetal and concentrated within 350 mm of the upper part of the ingot. Tangential magnetic field is generated by smelting current and axial magnetic field is generated by stirring current, which are simply coupled. Under the action of smelting current and its self-induced magnetic field, radial and axial electromagnetic forces are generated; the electromagnetic force rotates under the action of the stirring magnetic field, generating tangential electromagnetic force. With the change of smelting current, the tangential component of magnetic field and the radial and axial resultant force of electromagnetic force change linearly. The axial component of the magnetic field and the radial component of the electromagnetic force change linearly with the stirring current.
The Maxwell 3D module in Ansys Electromagnetics Suite was used to establish a mathematical and physical model for electromagnetic field in the vacuum arc remelting process of titanium alloy, and the interaction law of current, magnetic field and electromagnetic force in the melting process was analyzed. The results show that the current in the ingot is centripetal and concentrated within 350 mm of the upper part of the ingot. Tangential magnetic field is generated by smelting current and axial magnetic field is generated by stirring current, which are simply coupled. Under the action of smelting current and its self-induced magnetic field, radial and axial electromagnetic forces are generated; the electromagnetic force rotates under the action of the stirring magnetic field, generating tangential electromagnetic force. With the change of smelting current, the tangential component of magnetic field and the radial and axial resultant force of electromagnetic force change linearly. The axial component of the magnetic field and the radial component of the electromagnetic force change linearly with the stirring current.
2023, 52(6):2002-2009.
DOI: 10.12442/j.issn.1002-185X.20220943
Abstract:
In order to understand the influence of the different aging parameters on the microstructure and mechanical properties of Ti-6Al-3Nb-2Zr-Mo (Ti6321) alloy, the microstructures and mechanical properties under different aging parameters (temperatures ranging from 500 °C to 650 °C, 3–24 h) were investigated by optical microscopy (OM), scanning electron microscopy (SEM), transmission electron microscopy (TEM), and mechanical properties tests. The results reveal that the secondary α phase (αs) is more sensitive to the aging parameters than the primary α phase (αp). Moreover, the thickness of αs phase is positively correlated with aging temperature or aging time. As the aging temperature and aging time increase, the segregation of Ti and Al elements in the β transformation phase (βt) becomes obvious, and the αs phase changes from fine needle-like to long rod-like. When the alloy is aged at 600 °C for 12 h, the alloy shows good comprehensive mechanical performance. The tensile strength, yield strength, and elongation are 907 MPa, 796 MPa, and 16%, respectively, and the impact energy is 55 J.
In order to understand the influence of the different aging parameters on the microstructure and mechanical properties of Ti-6Al-3Nb-2Zr-Mo (Ti6321) alloy, the microstructures and mechanical properties under different aging parameters (temperatures ranging from 500 °C to 650 °C, 3–24 h) were investigated by optical microscopy (OM), scanning electron microscopy (SEM), transmission electron microscopy (TEM), and mechanical properties tests. The results reveal that the secondary α phase (αs) is more sensitive to the aging parameters than the primary α phase (αp). Moreover, the thickness of αs phase is positively correlated with aging temperature or aging time. As the aging temperature and aging time increase, the segregation of Ti and Al elements in the β transformation phase (βt) becomes obvious, and the αs phase changes from fine needle-like to long rod-like. When the alloy is aged at 600 °C for 12 h, the alloy shows good comprehensive mechanical performance. The tensile strength, yield strength, and elongation are 907 MPa, 796 MPa, and 16%, respectively, and the impact energy is 55 J.
10 Synergistic between corrosion and wear of TC4 alloy in artificial seawater and artificial acid rain
2023, 52(6):2075-2084.
DOI: 10.12442/j.issn.1002-185X.20220807
Abstract:
The corrosive lubricanting environments that TC4 alloy being exposed can result in severe corrosion wear. Corrosion wear experiments were carried out to explore the corrosion and wear mechanisms of TC4 alloy, as well as the synergistic between corrosion and wear. In this experiment, distilled water, artificial acid rain, and artificial seawater were selected as corrosive lubricating media for the GCr15/TC4 friction counterpart. The Anton Paar TRB3 tester were used for the experiments. The results suggest that the wear mechanisms of TC4 alloy in three water-based media are significantly different. Adhesive wear is most pronounced in distilled water, as well as fatigue delamination dominates in artificial seawater, however, abrasive wear is most significant in acid rain. The wear length, width, depth and volume of the wear profiles in acid rain are greater than those in artificial seawater and distilled water. The wear volume of TC4 alloy in artificial acid rain is larger than that in artificial seawater and distilled water, and it increased linearly with the number of cycles and normal loads. It shows that GCr15/TC4 is the most sensitive to acid rain, as well as suffers the most serious damage. In these three media, the synergistic factor of TC4 corrosion and wear in descending order is artificial acid rain, artificial seawater, and distilled water. The wear loss of TC4 alloy in distilled water is dominated by mechanical factors, while in artificial seawater and acid rain is dominated by corrosion-wear interaction and mechanical factors. The synergistic factor decreases as the load increases, and the influence of mechanical factors on corrosion wear becomes more significant.
The corrosive lubricanting environments that TC4 alloy being exposed can result in severe corrosion wear. Corrosion wear experiments were carried out to explore the corrosion and wear mechanisms of TC4 alloy, as well as the synergistic between corrosion and wear. In this experiment, distilled water, artificial acid rain, and artificial seawater were selected as corrosive lubricating media for the GCr15/TC4 friction counterpart. The Anton Paar TRB3 tester were used for the experiments. The results suggest that the wear mechanisms of TC4 alloy in three water-based media are significantly different. Adhesive wear is most pronounced in distilled water, as well as fatigue delamination dominates in artificial seawater, however, abrasive wear is most significant in acid rain. The wear length, width, depth and volume of the wear profiles in acid rain are greater than those in artificial seawater and distilled water. The wear volume of TC4 alloy in artificial acid rain is larger than that in artificial seawater and distilled water, and it increased linearly with the number of cycles and normal loads. It shows that GCr15/TC4 is the most sensitive to acid rain, as well as suffers the most serious damage. In these three media, the synergistic factor of TC4 corrosion and wear in descending order is artificial acid rain, artificial seawater, and distilled water. The wear loss of TC4 alloy in distilled water is dominated by mechanical factors, while in artificial seawater and acid rain is dominated by corrosion-wear interaction and mechanical factors. The synergistic factor decreases as the load increases, and the influence of mechanical factors on corrosion wear becomes more significant.
2023, 52(6):2126-2133.
DOI: 10.12442/j.issn.1002-185X.20220461
Abstract:
Additively manufactured TC4 alloy has attracted extensive attention due to its short processing cycle, high dimensional accuracy and good forming quality. However, the research on its high-temperature mechanical properties and corrosion behavior in Cl- containing solution after heat treatment is relatively scarce. In this study, TC4 alloy was fabricated by selective laser melting (SLM). The microstructure, high-temperature mechanical properties and corrosion behavior of TC4 alloy after heat treatment were studied by optical microscope, scanning electron microscope, X-ray diffractometer, universal tensile testing machine and electrochemical testing, and compared with as-cast TC4 alloy. The results show that the phase composition of SLM is the same as that of cast TC4 alloy. The microstructure of SLM TC4 alloy is mainly lamellar (α+β) phase, with an average grain area of about 2 μm2, while the as-cast TC4 alloy shows a typical Widmanstatten structure, and the average grain area is about 276 μm2. Compared with as-cast TC4 alloy, SLM TC4 alloy possesses excellent mechanical properties at both room temperature and high temperature, and the passivation film formed on its surface has better protection performance, resulting in a lower corrosion rate.
Additively manufactured TC4 alloy has attracted extensive attention due to its short processing cycle, high dimensional accuracy and good forming quality. However, the research on its high-temperature mechanical properties and corrosion behavior in Cl- containing solution after heat treatment is relatively scarce. In this study, TC4 alloy was fabricated by selective laser melting (SLM). The microstructure, high-temperature mechanical properties and corrosion behavior of TC4 alloy after heat treatment were studied by optical microscope, scanning electron microscope, X-ray diffractometer, universal tensile testing machine and electrochemical testing, and compared with as-cast TC4 alloy. The results show that the phase composition of SLM is the same as that of cast TC4 alloy. The microstructure of SLM TC4 alloy is mainly lamellar (α+β) phase, with an average grain area of about 2 μm2, while the as-cast TC4 alloy shows a typical Widmanstatten structure, and the average grain area is about 276 μm2. Compared with as-cast TC4 alloy, SLM TC4 alloy possesses excellent mechanical properties at both room temperature and high temperature, and the passivation film formed on its surface has better protection performance, resulting in a lower corrosion rate.
2023, 52(6):2212-2219.
DOI: 10.12442/j.issn.1002-185X.20220492
Abstract:
To reveal the effect of trace W addition on the hot workability of the Mn-containing β-solidifying γ-TiAl, the Ti-42Al-5Mn-0.8W alloy (at.%, the same below) were refined with a vacuum induction furnace. Hot deformation behavior of the alloy was studied at the temperature of 1100~1250 ℃, stran rate range of 0.001~10 s-1 and maximum deformation degree of 70% with thermal simulator. It shows that the range of appropriate thermal processing parameters are 1150~1250℃/0.001~10 s-1 and 1100~1145 ℃/0.001~1 s-1. 0.8 at.% W addition can obviously reduce the peak flow stress of Ti-42Al-5Mn alloy(σp) and steady-state flow stress(σ0.7), and the steady-state flow stress decreases more significantly. The main reason why 0.8 at.% W improves the hot workability of Ti-42Al-5Mn alloy is that on the one hand, the W content is relatively small, and the segregation degree of W element is not obvious under the vacuum induction melting mode with strong electromagnetic stirring; On the other hand, thanks to the fact that the β-stabilizing effect of W is stronger than that of Mn, extending the region of β single phase zone, thus having a wider processing window that can be thermally deformed.
To reveal the effect of trace W addition on the hot workability of the Mn-containing β-solidifying γ-TiAl, the Ti-42Al-5Mn-0.8W alloy (at.%, the same below) were refined with a vacuum induction furnace. Hot deformation behavior of the alloy was studied at the temperature of 1100~1250 ℃, stran rate range of 0.001~10 s-1 and maximum deformation degree of 70% with thermal simulator. It shows that the range of appropriate thermal processing parameters are 1150~1250℃/0.001~10 s-1 and 1100~1145 ℃/0.001~1 s-1. 0.8 at.% W addition can obviously reduce the peak flow stress of Ti-42Al-5Mn alloy(σp) and steady-state flow stress(σ0.7), and the steady-state flow stress decreases more significantly. The main reason why 0.8 at.% W improves the hot workability of Ti-42Al-5Mn alloy is that on the one hand, the W content is relatively small, and the segregation degree of W element is not obvious under the vacuum induction melting mode with strong electromagnetic stirring; On the other hand, thanks to the fact that the β-stabilizing effect of W is stronger than that of Mn, extending the region of β single phase zone, thus having a wider processing window that can be thermally deformed.
2023, 52(6):2010-2016.
DOI: 10.12442/j.issn.1002-185X.E20220032
Abstract:
Explosively welded Ti/steel clad plates were one-pass warm rolled by 60%, microstructures of the Ti layer and steel layer adjacent to interface were investigated, and shear strength of the one-pass warm rolled clad plates was tested. Results show that the one-pass warm rolling process can cause obvious shear deformation in both the Ti layer and steel layer adjacent to the interface. Because of the shear deformation, the RD-split basal texture forms in the Ti layer. In the steel layer, high fraction of the rotated cube texture and low fraction of the γ fiber texture form. Compared with the common multi-pass rolling method, shear strength of the one-pass warm rolled Ti/steel clad plate is improved because the shear deformation refines the interfacial compounds.
Explosively welded Ti/steel clad plates were one-pass warm rolled by 60%, microstructures of the Ti layer and steel layer adjacent to interface were investigated, and shear strength of the one-pass warm rolled clad plates was tested. Results show that the one-pass warm rolling process can cause obvious shear deformation in both the Ti layer and steel layer adjacent to the interface. Because of the shear deformation, the RD-split basal texture forms in the Ti layer. In the steel layer, high fraction of the rotated cube texture and low fraction of the γ fiber texture form. Compared with the common multi-pass rolling method, shear strength of the one-pass warm rolled Ti/steel clad plate is improved because the shear deformation refines the interfacial compounds.
2023, 52(6):2017-2023.
DOI: 10.12442/j.issn.1002-185X.20221003
Abstract:
In order to reveal the diffusion behavior of Ti/Al interface, the molecular dynamics simulation was applied to study the microscopic diffusion mechanisms of Ti/Al explosive welding interface at the atomic scale. Molecular dynamics model of Ti/Al explosive welding spot was established by Materials Studio (MS). According to the physical process of explosive welding, the simulation of the collision was divided into two stages: the loading stage and the unloading stage. The mean square displacement (MSD), radial distribution function (RDF), and diffusion layer thickness were calculated by LAMMPS, and the diffusion behavior of interfacial atoms at different stages was reproduced by OVITO. Results show that in the loading stage of explosive welding, Ti and Al atoms do not diffuse but only vibrate at the equilibrium position, and the vibration of Al atoms is stronger than that of Ti atoms. The atomic diffusion only occurs in the unloading stage of the explosive welding process. The Ti-Ti bonding energy is too high to break. The Al-Al bonding energy is low, so it is easy to be damaged, resulting in vacancies, gaps and other defects, which promotes the deep diffusion of Ti atoms into the Al substrate lattice while hindering Al atoms from entering the Ti substrate lattice. The simulation result is basically in accordance with EDS experimental result.
In order to reveal the diffusion behavior of Ti/Al interface, the molecular dynamics simulation was applied to study the microscopic diffusion mechanisms of Ti/Al explosive welding interface at the atomic scale. Molecular dynamics model of Ti/Al explosive welding spot was established by Materials Studio (MS). According to the physical process of explosive welding, the simulation of the collision was divided into two stages: the loading stage and the unloading stage. The mean square displacement (MSD), radial distribution function (RDF), and diffusion layer thickness were calculated by LAMMPS, and the diffusion behavior of interfacial atoms at different stages was reproduced by OVITO. Results show that in the loading stage of explosive welding, Ti and Al atoms do not diffuse but only vibrate at the equilibrium position, and the vibration of Al atoms is stronger than that of Ti atoms. The atomic diffusion only occurs in the unloading stage of the explosive welding process. The Ti-Ti bonding energy is too high to break. The Al-Al bonding energy is low, so it is easy to be damaged, resulting in vacancies, gaps and other defects, which promotes the deep diffusion of Ti atoms into the Al substrate lattice while hindering Al atoms from entering the Ti substrate lattice. The simulation result is basically in accordance with EDS experimental result.
2023, 52(6):2024-2030.
DOI: 10.12442/j.issn.1002-185X.E20220041
Abstract:
TiAlN coatings were deposited at various deposition temperatures using vacuum arc ion plating (AIP) for the high performance manufacture. The relationships between deposition temperatures and surface properties were investigated. Results show that surface macroparticles (MPs) decrease in number and size with increasing the deposition temperature because of ion bombardment. When deposition temperature increases, the grain size on the top coating first decreases sharply, and then increases gradually. Furthermore, deposition temperature has little influence on the phase constituents and chemical compositions of the resultant coatings. With raising the deposition temperature, the hardness and adhesion strength first increase rapidly, and then decrease gradually. The deposited TiAlN coating exhibits the highest hardness and the strongest adhesion strength when deposition temperature is set at around 450 °C. The mechanism of the above phenomena is attributed to the variations of microstructure and residual stress between the surface and interface during the deposition process. The resultant coatings have a good thermal stability in air at temperatures up to 900 °C.
TiAlN coatings were deposited at various deposition temperatures using vacuum arc ion plating (AIP) for the high performance manufacture. The relationships between deposition temperatures and surface properties were investigated. Results show that surface macroparticles (MPs) decrease in number and size with increasing the deposition temperature because of ion bombardment. When deposition temperature increases, the grain size on the top coating first decreases sharply, and then increases gradually. Furthermore, deposition temperature has little influence on the phase constituents and chemical compositions of the resultant coatings. With raising the deposition temperature, the hardness and adhesion strength first increase rapidly, and then decrease gradually. The deposited TiAlN coating exhibits the highest hardness and the strongest adhesion strength when deposition temperature is set at around 450 °C. The mechanism of the above phenomena is attributed to the variations of microstructure and residual stress between the surface and interface during the deposition process. The resultant coatings have a good thermal stability in air at temperatures up to 900 °C.
16 An Improved Lemaitre Fracture Criterion and Its Application to Crack Prediction in Bending Forming
2023, 52(6):2031-2038.
DOI: 10.12442/j.issn.1002-185X.20220888
Abstract:
In order to predict the crack defects in sheet metal bending, an Lemaitre criterion was improved to effectively predict the forming limit in bending while considering the stress triaxiality
In order to predict the crack defects in sheet metal bending, an Lemaitre criterion was improved to effectively predict the forming limit in bending while considering the stress triaxiality
2023, 52(6):2039-2047.
DOI: 10.12442/j.issn.1002-185X.20220907
Abstract:
Al-Cu alloy with wide solidification interval is prone to hot tearing and porosity defects due to insufficient feeding. The effect of hydrogen content on the hot tearing susceptibility (HTS) of Al-xCu alloy was investigated by the constrained rod casting (CRC) mold. Based on analysis of the HTS value, fracture morphology and the microstructure of Al-xCu alloy with different hydrogen contents in the melt, the influence of porosity formation on the hot tearing was analyzed. The results show that the hot tearing susceptibility of the alloy is evidently aggravated, which is caused by grain coarsening and insufficient feeding of liquid phase in the late stage of solidification with the increase in melt hydrogen content. A porosity-based formation mechanism of hot tearing is proposed to explain the interplay between porosity and hot tearing.
Al-Cu alloy with wide solidification interval is prone to hot tearing and porosity defects due to insufficient feeding. The effect of hydrogen content on the hot tearing susceptibility (HTS) of Al-xCu alloy was investigated by the constrained rod casting (CRC) mold. Based on analysis of the HTS value, fracture morphology and the microstructure of Al-xCu alloy with different hydrogen contents in the melt, the influence of porosity formation on the hot tearing was analyzed. The results show that the hot tearing susceptibility of the alloy is evidently aggravated, which is caused by grain coarsening and insufficient feeding of liquid phase in the late stage of solidification with the increase in melt hydrogen content. A porosity-based formation mechanism of hot tearing is proposed to explain the interplay between porosity and hot tearing.
2023, 52(6):2048-2056.
DOI: 10.12442/j.issn.1002-185X.20220912
Abstract:
The effect of Sc addition on the corrosion behavior of as-cast Al-3Cu-1Li alloy in 2 mol/L NaCl acidic solution was studied. The phase compositions of as-cast Al-3Cu-1Li-xSc (mass fraction) alloys were determined by XRD. The microstructures of Al-3Cu-1Li alloy and Al-3Cu-1Li-0.5Sc alloy were observed by FE-SEM/EDS and TEM. The corrosion behavior of the alloy was studied by potentiodynamic polarization, EIS, EN and immersion test, and the corrosion mechanism was discussed. The results show that Cu-rich spherical phases are distributed in the grain of Al-Cu-1Li alloy; Cu-rich spherical phase is reduced, and W phase precipitates at the grain boundary of Al-3Cu-1Li alloys containing Sc. Sc can reduce the corrosion reaction activation energy of the alloys, making the corrosion process easier. With increasing the Sc content, cathode hydrogen evolution rate increases, the self-corrosion current density of the alloy increases, and the corrosion resistance decreases gradually. EN and EIS results show that the surfaces of Al-3Cu-1Li alloy and Al-3Cu-1Li-0.1Sc alloy are in the state of “film rupture-repassivation” during 12 h immersion in the solution, and Al-3Cu-1Li-0.3Sc alloy and Al-3Cu-1Li-0.5Sc alloy have severe intergranular corrosion.
The effect of Sc addition on the corrosion behavior of as-cast Al-3Cu-1Li alloy in 2 mol/L NaCl acidic solution was studied. The phase compositions of as-cast Al-3Cu-1Li-xSc (mass fraction) alloys were determined by XRD. The microstructures of Al-3Cu-1Li alloy and Al-3Cu-1Li-0.5Sc alloy were observed by FE-SEM/EDS and TEM. The corrosion behavior of the alloy was studied by potentiodynamic polarization, EIS, EN and immersion test, and the corrosion mechanism was discussed. The results show that Cu-rich spherical phases are distributed in the grain of Al-Cu-1Li alloy; Cu-rich spherical phase is reduced, and W phase precipitates at the grain boundary of Al-3Cu-1Li alloys containing Sc. Sc can reduce the corrosion reaction activation energy of the alloys, making the corrosion process easier. With increasing the Sc content, cathode hydrogen evolution rate increases, the self-corrosion current density of the alloy increases, and the corrosion resistance decreases gradually. EN and EIS results show that the surfaces of Al-3Cu-1Li alloy and Al-3Cu-1Li-0.1Sc alloy are in the state of “film rupture-repassivation” during 12 h immersion in the solution, and Al-3Cu-1Li-0.3Sc alloy and Al-3Cu-1Li-0.5Sc alloy have severe intergranular corrosion.
2023, 52(6):2057-2062.
DOI: 10.12442/j.issn.1002-185X.20220689
Abstract:
The evolution of microstructures and mechanical properties stimulated by long-term service was investigated using a GTD111 blade employed in the first stage rotor blade of a heavy-duty gas turbine. Results show that the microstructures of the blade are mainly composed of γ matrix, γ′ precipitates with two dimensions, γ+γ′ eutectic and MC-type carbides. The microstructural degradation of the blade is closely related to its structural characteristics. Samples from leading edge and middle region of the blade exhibit a relatively lower degree of microstructural degradation, while samples from trailing edge of the blade possess higher degree of microstructural degradation. The ultimate tensile strength (UTS) of the leading edge region is significantly higher than that of the trailing edge region at room temperature, but the UTS of different regions has little difference at 982 °C, which may be related to different deformation mechanisms at higher temperatures.
The evolution of microstructures and mechanical properties stimulated by long-term service was investigated using a GTD111 blade employed in the first stage rotor blade of a heavy-duty gas turbine. Results show that the microstructures of the blade are mainly composed of γ matrix, γ′ precipitates with two dimensions, γ+γ′ eutectic and MC-type carbides. The microstructural degradation of the blade is closely related to its structural characteristics. Samples from leading edge and middle region of the blade exhibit a relatively lower degree of microstructural degradation, while samples from trailing edge of the blade possess higher degree of microstructural degradation. The ultimate tensile strength (UTS) of the leading edge region is significantly higher than that of the trailing edge region at room temperature, but the UTS of different regions has little difference at 982 °C, which may be related to different deformation mechanisms at higher temperatures.
20 Microstructure and Properties of a Ferromagnetic Damping Alloy Fabricated by Spark Plasma Sintering
2023, 52(6):2063-2067.
DOI: 10.12442/j.issn.1002-185X.20220984
Abstract:
A Fe-16Cr-2.5Mo (wt%) damping alloy was prepared by spark plasma sintering (referred to SPS alloy) and vacuum induction melting followed by forging and annealing (referred to VIMFA alloy). The comparative study on microstructure, magnetic performance, damping capacity and mechanical property of SPS and VIMFA alloys was conducted. Results show that the relatively high compactness of SPS alloy is obtained. The dissolution of Cr and Mo in α-Fe solid solution is obviously promoted and the homogeneity of microstructure of SPS alloy is dramatically ameliorated with increase in sintering temperature and extension in holding time. SPS alloys exhibit relatively lower saturation magnetization but higher coercivity than VIMFA ones. There is still favorable damping capacity for SPS alloys despite it is lower than that of VIMFA one. Furthermore, the damping capacity of SPS alloy slightly rises with increase in sintering temperature and extension in holding time. The SPS alloys possess evidently higher compression strength than VIMFA ones. Also, the compression strength of SPS alloy rises with increase in sintering temperature.
A Fe-16Cr-2.5Mo (wt%) damping alloy was prepared by spark plasma sintering (referred to SPS alloy) and vacuum induction melting followed by forging and annealing (referred to VIMFA alloy). The comparative study on microstructure, magnetic performance, damping capacity and mechanical property of SPS and VIMFA alloys was conducted. Results show that the relatively high compactness of SPS alloy is obtained. The dissolution of Cr and Mo in α-Fe solid solution is obviously promoted and the homogeneity of microstructure of SPS alloy is dramatically ameliorated with increase in sintering temperature and extension in holding time. SPS alloys exhibit relatively lower saturation magnetization but higher coercivity than VIMFA ones. There is still favorable damping capacity for SPS alloys despite it is lower than that of VIMFA one. Furthermore, the damping capacity of SPS alloy slightly rises with increase in sintering temperature and extension in holding time. The SPS alloys possess evidently higher compression strength than VIMFA ones. Also, the compression strength of SPS alloy rises with increase in sintering temperature.
2023, 52(6):2068-2074.
DOI: 10.12442/j.issn.1002-185X.E20230004
Abstract:
The Mg-3Y (wt%) alloy sheet was fabricated by pre-extrusion and subsequent single-pass large strain hot rolling process. The influences of different twinning types on dynamic recrystallization (DRX) and grain structure evolution during large strain hot rolling were investigated. Results show that the alloy undergoes nearly complete DRX during pre-extrusion processing under a low extrusion ratio of 8:1. During subsequent large strain hot rolling processing, deformation twinning, especially the {10
The Mg-3Y (wt%) alloy sheet was fabricated by pre-extrusion and subsequent single-pass large strain hot rolling process. The influences of different twinning types on dynamic recrystallization (DRX) and grain structure evolution during large strain hot rolling were investigated. Results show that the alloy undergoes nearly complete DRX during pre-extrusion processing under a low extrusion ratio of 8:1. During subsequent large strain hot rolling processing, deformation twinning, especially the {10
2023, 52(6):2085-2092.
DOI: 10.12442/j.issn.1002-185X.20220609
Abstract:
The microstructure of the 7075 aluminum alloy, which was extruded before the preparation of a semi-solid isothermal remelting billet, was studied in this paper along with the effects of isothermal temperature and holding time. The grain coarse-grain law was predicted using the grain-growth model in the JMAK module of DEFORM-3D software. The findings demonstrate that the grain size gradually rises, the grain tends to be rounded, and the liquid content of the grain border increases with increasing isothermal temperature and holding time. During the high solid fraction interval, the grains underwent recrystallization, merged and grown, and liquid phase increased. In the low solid fraction interval, non-recrystallized grains are rarely visible, and Ostwald ripening is the primary mechanism causing the grains to grow quickly. In the semi-solid isothermal remelting grain growth formula, n=3 is a more accurate value. The rate of grain growth is calculated at 55.1 μm3/s, 295.3 μm3/s and 817.9 μm3/s as isothermal temperature rises. Using the energy relation and grain growth formula, the activation energy of the grain boundary migration of the 7075 aluminum alloy was calculated to be 118.6 kJ/mol, with a grain growth rule in the 550-620 °C range predicted. The actual measured value and the expected value are relatively close.
The microstructure of the 7075 aluminum alloy, which was extruded before the preparation of a semi-solid isothermal remelting billet, was studied in this paper along with the effects of isothermal temperature and holding time. The grain coarse-grain law was predicted using the grain-growth model in the JMAK module of DEFORM-3D software. The findings demonstrate that the grain size gradually rises, the grain tends to be rounded, and the liquid content of the grain border increases with increasing isothermal temperature and holding time. During the high solid fraction interval, the grains underwent recrystallization, merged and grown, and liquid phase increased. In the low solid fraction interval, non-recrystallized grains are rarely visible, and Ostwald ripening is the primary mechanism causing the grains to grow quickly. In the semi-solid isothermal remelting grain growth formula, n=3 is a more accurate value. The rate of grain growth is calculated at 55.1 μm3/s, 295.3 μm3/s and 817.9 μm3/s as isothermal temperature rises. Using the energy relation and grain growth formula, the activation energy of the grain boundary migration of the 7075 aluminum alloy was calculated to be 118.6 kJ/mol, with a grain growth rule in the 550-620 °C range predicted. The actual measured value and the expected value are relatively close.
2023, 52(6):2093-2102.
DOI: 10.12442/j.issn.1002-185X.20220414
Abstract:
This paper studied the effect of residual stress on the reheat cracking susceptibility of Super304H austenitic stainless steel weld metal using the pre-compressed CT specimen method. The plastic strain and dislocation density distribution of weld metal under different residual stresses were analyzed by ABAQUS simulation combined with EBSD characterization. The effect of residual stress on the reheat cracking susceptibility is explained from the aspect of stress-induced precipitation. The results show that CT specimens with high pre-compression force have higher residual stress and are more likely to generate cracks. As the residual stress increases, the tensile strength of the tensile specimen decreases gradually. The high residual stress region of the CT specimen closed to the U-shaped notch root has higher dislocation density and subgrain, promoting the precipitation of the small intragranuar phase, which makes the intragranular hardening more serious, and reheat cracking are easier to occur.
This paper studied the effect of residual stress on the reheat cracking susceptibility of Super304H austenitic stainless steel weld metal using the pre-compressed CT specimen method. The plastic strain and dislocation density distribution of weld metal under different residual stresses were analyzed by ABAQUS simulation combined with EBSD characterization. The effect of residual stress on the reheat cracking susceptibility is explained from the aspect of stress-induced precipitation. The results show that CT specimens with high pre-compression force have higher residual stress and are more likely to generate cracks. As the residual stress increases, the tensile strength of the tensile specimen decreases gradually. The high residual stress region of the CT specimen closed to the U-shaped notch root has higher dislocation density and subgrain, promoting the precipitation of the small intragranuar phase, which makes the intragranular hardening more serious, and reheat cracking are easier to occur.
2023, 52(6):2103-2110.
DOI: 10.12442/j.issn.1002-185X.20220427
Abstract:
Amorphous indium gallium zinc oxide thin film transistors (a-IGZO TFTs) have the advantages of high field effect mobility and high switching ratio, and thus exhibit great potential applications in the fields of active drive display technology, flexible and wearable electronic devices. However, the poor stability of the electronic performances is the key problem restricting its large-scale applications. In this paper, Al2O3 thin films with low oxygen vacancy content were prepared by hollow cathode assistant pulsed laser deposition at room temperature, and used as the passivation layer of a-IGZO TFT devices. In-depth X-ray photoelectron spectroscopy illustrates that oxygen plasma introduced by the hollow cathode inhibits the formation of oxygen vacancies at the Al2O3/a-IGZO interface, which could improve the subthreshold performances of the TFT devices. 180 oC annealing for a-IGZO films could improve the mobility and reduce the threshold voltage shift; Annealing at 100 oC for Al2O3/a-IGZO TFT devices is helpful to reduce the carrier concentration and improve the subthreshold characteristics. The mobility of TFT devices processed by these two combining annealing processes could be as high as 22.8 cm2V-1s-1, and the subthreshold swing is 0.6 Vdecade-1.
Amorphous indium gallium zinc oxide thin film transistors (a-IGZO TFTs) have the advantages of high field effect mobility and high switching ratio, and thus exhibit great potential applications in the fields of active drive display technology, flexible and wearable electronic devices. However, the poor stability of the electronic performances is the key problem restricting its large-scale applications. In this paper, Al2O3 thin films with low oxygen vacancy content were prepared by hollow cathode assistant pulsed laser deposition at room temperature, and used as the passivation layer of a-IGZO TFT devices. In-depth X-ray photoelectron spectroscopy illustrates that oxygen plasma introduced by the hollow cathode inhibits the formation of oxygen vacancies at the Al2O3/a-IGZO interface, which could improve the subthreshold performances of the TFT devices. 180 oC annealing for a-IGZO films could improve the mobility and reduce the threshold voltage shift; Annealing at 100 oC for Al2O3/a-IGZO TFT devices is helpful to reduce the carrier concentration and improve the subthreshold characteristics. The mobility of TFT devices processed by these two combining annealing processes could be as high as 22.8 cm2V-1s-1, and the subthreshold swing is 0.6 Vdecade-1.
2023, 52(6):2111-2117.
DOI: 10.12442/j.issn.1002-185X.20220851
Abstract:
ZrAl alloy is a potential space material for aerospace. Zr-6Al-0.1B alloy was prepared by vacuum hot pressing sintering. The isothermal compression tests of hot-pressed sintered Zr-6Al-0.1B alloy were carried out under the conditions of deformation temperature 950 ℃ ~ 1150 ℃ and strain rate 0.01 s-1 ~ 1 s-1 using Gleeble-3500 thermal simulation machine. The results show that at the beginning of deformation, the stress increases rapidly with the increase of strain and reaches the peak quickly. Then, the stress decreases continuously with the increase of strain, and there is no stress equilibrium stage. With the decrease of the deformation temperature or the increase of the strain rate, the stress-strain curve shifts to the high stress region, indicating that the hot-pressed sintered Zr-6Al-0.1B alloy is a sensitive material for deformation temperature and strain rate. The Johnson-Cook constitutive model of hot-pressed sintered Zr-6Al-0.1B alloy was established, the temperature sensitivity coefficient D and strain rate sensitivity coefficient C were modified. Through qualitative and quantitative comparative analysis between the predicted value by the model and the tested value, indicating the model has higher prediction accuracy when C is modified alone. This study can provide guidance for the selection of subsequent hot working parameters of hot-pressed sintered Zr-6Al-0.1B alloy, and provide a reliable constitutive model for the corresponding numerical simulation research.
ZrAl alloy is a potential space material for aerospace. Zr-6Al-0.1B alloy was prepared by vacuum hot pressing sintering. The isothermal compression tests of hot-pressed sintered Zr-6Al-0.1B alloy were carried out under the conditions of deformation temperature 950 ℃ ~ 1150 ℃ and strain rate 0.01 s-1 ~ 1 s-1 using Gleeble-3500 thermal simulation machine. The results show that at the beginning of deformation, the stress increases rapidly with the increase of strain and reaches the peak quickly. Then, the stress decreases continuously with the increase of strain, and there is no stress equilibrium stage. With the decrease of the deformation temperature or the increase of the strain rate, the stress-strain curve shifts to the high stress region, indicating that the hot-pressed sintered Zr-6Al-0.1B alloy is a sensitive material for deformation temperature and strain rate. The Johnson-Cook constitutive model of hot-pressed sintered Zr-6Al-0.1B alloy was established, the temperature sensitivity coefficient D and strain rate sensitivity coefficient C were modified. Through qualitative and quantitative comparative analysis between the predicted value by the model and the tested value, indicating the model has higher prediction accuracy when C is modified alone. This study can provide guidance for the selection of subsequent hot working parameters of hot-pressed sintered Zr-6Al-0.1B alloy, and provide a reliable constitutive model for the corresponding numerical simulation research.
2023, 52(6):2141-2146.
DOI: 10.12442/j.issn.1002-185X.20220399
Abstract:
In order to solve the problem of poor thermal conductivity of traditional tool coatings with high wear resistance, the (TiAlTaCrZr)N coatings were prepared by DC magnetron sputtering under different nitrogen flow rates. The effects of different nitrogen contents on the microstructure, hardness, adhesion and thermal conductivity of the coatings were studied. With the increase of nitrogen flow rates, the content of N in the coatings increases, and the microstructure of the coatings changes from nanocrystalline to columnar crystal. The hardness of the coatings increases from 11.0 GPa of the TiAlTaCrZr coating to 20.6 GPa of the (TiAlTaCrZr)N coating with 5 SCCM nitrogen flow rate. The adhesion of the coating reaches to the value of 130 N when nitrogen flow is 5 SCCM, and then decreases gradually with the increase of nitrogen contents. The thermal conductivity of the (TiAlTaCrZr)N coating is better than that of the TiAlN coating, but the thermal conductivity decreases with the increase of nitrogen contents. Since the (TiAlTaCrZr)N coating have high thermal conductivity, high adhesion and high hardness, the cutting length of the (TiAlTaCrZr)N coating is 175% higher than that of the TiAlN coating for titanium alloy cutting. It provides a new tool coating with high wear resistance and high thermal conductivity for titanium alloy cutting.
In order to solve the problem of poor thermal conductivity of traditional tool coatings with high wear resistance, the (TiAlTaCrZr)N coatings were prepared by DC magnetron sputtering under different nitrogen flow rates. The effects of different nitrogen contents on the microstructure, hardness, adhesion and thermal conductivity of the coatings were studied. With the increase of nitrogen flow rates, the content of N in the coatings increases, and the microstructure of the coatings changes from nanocrystalline to columnar crystal. The hardness of the coatings increases from 11.0 GPa of the TiAlTaCrZr coating to 20.6 GPa of the (TiAlTaCrZr)N coating with 5 SCCM nitrogen flow rate. The adhesion of the coating reaches to the value of 130 N when nitrogen flow is 5 SCCM, and then decreases gradually with the increase of nitrogen contents. The thermal conductivity of the (TiAlTaCrZr)N coating is better than that of the TiAlN coating, but the thermal conductivity decreases with the increase of nitrogen contents. Since the (TiAlTaCrZr)N coating have high thermal conductivity, high adhesion and high hardness, the cutting length of the (TiAlTaCrZr)N coating is 175% higher than that of the TiAlN coating for titanium alloy cutting. It provides a new tool coating with high wear resistance and high thermal conductivity for titanium alloy cutting.
2023, 52(6):2147-2153.
DOI: 10.12442/j.issn.1002-185X.20220433
Abstract:
The thermal barrier coating prepared by atmospheric plasma spraying was modified by high-current pulsed electron beam. The original coating and the electron beam modified coating were subjected to CMAS corrosion experiments at 1250℃, respectively. The phase composition, microstructure and chemical composition of the original coating and the electron beam modified coating before and after corrosion were characterized by XRD, SEM and EDS, and the CMAS corrosion behaviors and influence laws of the original coating and the modified coating were compared and analyzed. The results show that the surface roughness of the modified coating decreases, and a dense remelting layer with columnar crystals is formed. The surface of the coating has better structural stability and phase stability. After 8 hours of CMAS corrosion, the structure of the modified coating remains intact, and the coating does not fail to fall off, so it has good resistance to CMAS corrosion.An experimental set-up was designed for measuring the self-field losses of Bi2223/Ag HTS tapes using a transport current method.
The thermal barrier coating prepared by atmospheric plasma spraying was modified by high-current pulsed electron beam. The original coating and the electron beam modified coating were subjected to CMAS corrosion experiments at 1250℃, respectively. The phase composition, microstructure and chemical composition of the original coating and the electron beam modified coating before and after corrosion were characterized by XRD, SEM and EDS, and the CMAS corrosion behaviors and influence laws of the original coating and the modified coating were compared and analyzed. The results show that the surface roughness of the modified coating decreases, and a dense remelting layer with columnar crystals is formed. The surface of the coating has better structural stability and phase stability. After 8 hours of CMAS corrosion, the structure of the modified coating remains intact, and the coating does not fail to fall off, so it has good resistance to CMAS corrosion.An experimental set-up was designed for measuring the self-field losses of Bi2223/Ag HTS tapes using a transport current method.
2023, 52(6):2154-2160.
DOI: 10.12442/j.issn.1002-185X.20220403
Abstract:
AlCoCrCuFeNi high-entropy alloys (HEAs) were prepared by selective laser melting (SLM). The microstructure and high-temperature oxidation behaviors at 800℃, 1000℃ and 1200℃ were studied. The phase compositions and morphological characteristics of the oxide film were analyzed by X-ray diffractometer (XRD) and scanning electron microscope (SEM). Results indicate that the prepared AlCoCrCuFeNi HEA mainly contains BCC phase, BCC/B2 phase and a small amount of FCC phase, and the microstructure is a non-equilibrium heterostructure composed of long straight columnar dendrite and equiaxed cell structures. The HEAs have good oxidation resistance at three temperatures. The oxidation kinetics curves basically follow the parabolic law. The oxidation rate is determined by a clear dependence on temperature, which increases with the increase of temperature, and obvious voids and cracks appear in the oxide films, which provided channels for diffusion of elements that aggravate the oxidation reaction, resulting in the oxide film peeling becomes more and more serious. The main components of the oxide films are Cr2O3, Al2O3 and spinel MCr2O4 mixed oxides. The denser oxide film can effectively inhibit the matrix from being further oxidized and improve the anti-oxidant properties of SLM-prepared HEA.
AlCoCrCuFeNi high-entropy alloys (HEAs) were prepared by selective laser melting (SLM). The microstructure and high-temperature oxidation behaviors at 800℃, 1000℃ and 1200℃ were studied. The phase compositions and morphological characteristics of the oxide film were analyzed by X-ray diffractometer (XRD) and scanning electron microscope (SEM). Results indicate that the prepared AlCoCrCuFeNi HEA mainly contains BCC phase, BCC/B2 phase and a small amount of FCC phase, and the microstructure is a non-equilibrium heterostructure composed of long straight columnar dendrite and equiaxed cell structures. The HEAs have good oxidation resistance at three temperatures. The oxidation kinetics curves basically follow the parabolic law. The oxidation rate is determined by a clear dependence on temperature, which increases with the increase of temperature, and obvious voids and cracks appear in the oxide films, which provided channels for diffusion of elements that aggravate the oxidation reaction, resulting in the oxide film peeling becomes more and more serious. The main components of the oxide films are Cr2O3, Al2O3 and spinel MCr2O4 mixed oxides. The denser oxide film can effectively inhibit the matrix from being further oxidized and improve the anti-oxidant properties of SLM-prepared HEA.
